Ovzon P30 OTM
The Ovzon P30 is a broadband satellite terminal for on-the-move applications for Land, Maritime and Airborne applications.
Specifically designed to meet customers’ mission-critical needs, the Ovzon P30 is ideal for use in demanding environments that require more bandwidth, high performance, and resiliency. The terminal is optimized for applications on land, at sea, or in the air.
Technical Specifications
|
Transmit*
|
Up to 75 Mbps
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Receive*
|
Up to 225 Mbps
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
User Interface
|
WebGUI
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Data Interface
|
Ethernet (cable)
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions H/Ø
|
Land, maritime: 330 / 430 mm, 13.0 / 16.9 in
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
Airborne w/o radome: 330 / 398 mm, 13.0 / 15.7 in
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Weight
|
Land: Vehicle mounting, MIL radome: 17 kg, 37.4 lb.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
Maritime: Mast mounting, fiberglass radome: 18 kg, 39.6 lb.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
Airborne: Hatch mounting, w/o radome: 15 kg, 33.0 lb.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Environmental
|
IP66
|
|
Temperature
|
-40°C to +50°C, -40°F to +122°F
|
|
Power consumption
|
Operating 180 – 260 W
|
|
DC input**
|
24 VDC
|
|
AC input**
|
100 – 240 VAC 50/60 Hz
|
* Operating in Ovzon’s service, data rate depending
on location within coverage and satellite.
** Supplied to external power supply.
Download Datasheet
Ease of use
When operations are conducted in challenging situations, time is of the essence.
The Ovzon P30, with its optimal user experience and high data rate capacity, empowers users with reallime acquisition and operation. It supports transmit data rates up to 70 Mbps and receive data rates up to 120 Mbps, putting you in control.
